Asphalt mixing plant

Asphalt mixing plant
Model:IVM-1000
Brand:INVECH
Origin:Made In China
Category:Industrial Supplies / Construction Machine
Label:Model:IVM-1000 , MADE-IN-CHINA , NANYANG INVECH
Price: US $120000 / pc
Min. Order:1 pc

Product Description

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering





IVM Series mobile asphalt mixing plant inherits the advantages of IV series asphalt batch mixing plant, and adds new elements including: containerized size, modular design and trailer and mobile chassis which make it possible for container transportation, fast mobilization and relocation.


IVM Asphalt Plant is designed for small and medium-sized pavement project which need frequent relocation.



Complete plant can be dismantled and reinstalled in 5 days (not including the transportation period).



High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering







Parameter:



Model

IVM-700

IVM-1000

IVM-1500

IVM-2000

Capacity

60 t/h

80 t/h

120 t/h

160 t/h

Mixer Capacity

700 kg/batch

1000 kg/batch

1500 kg/batch

2000 kg/batch

Fuel Consumption

Diesel consumption: 5.5-7 kg/ton

Weighing Precision

Hot aggregate: ±0.5%; bitumen: ±0.3%; filler: ±0.2%

Hot Asphalt Temperature

130℃-165℃ (adjustable)

Air Emissions

≤ 20 mg/Nm³

Working Noise

≤ 70 db(A)

Operation

Full Auto/Manual Operation

Installation Power

157 kW

241 kW

330 kW

412 kW

Voltage

220V/380V-50Hz (adjustable)

Plant Covering Area

Length

35 m

40 m

40 m

42 m

Width

26 m

28 m

32 m

32 m

Height

15 m

15 m

16 m

16 m

Documents

Lay-Out/ Electric Circuit Diagram; Chinese-English Operation Manual; Qualification Certificate.









Main Features:



Drying System
1. Adopts four sets of famous powerful direct-connected gear motors to drive the drying drum;
2. Optimized blades make the drying process more balance with higher heat utilization rate;
3. Drying drum is covered by thermal insulation material and stainless steel skin to avoid heat loss;
4. Well calculated and carefully heat-treated drying drum, world-class bearings have a long service life and stable performance.

Dust Collecting System
1. Double dust collecting system, European emission standards;
2. Pulsating dust removal method, energy saving and efficient;
3. Durable key components;
4. Safety protection, intelligent inspection.

Vibrating Screen
1. Sturdy and durable, high intensity and remarkable screening effect;
2. Screen mesh easy to maintain and replace, time-saving;
3. Frequency and amplitude perfectly matched, over 95% grading precision, competent to any severe working situation, high-temperature resistance and excellent productivity;
4. Best design to guarantee the best screening result.
a. Adopts self-synchronizing driving technology, maintenance-free and environmental;
b. Patent enhanced drivable bridge structure design, tough and protective for screening components;
c. Famous vibrating motor.

Mixing System
1. Simulating optimization of material mixing movement speed;
2. Ensures each batch is totally and equally mixed with 25% mixing efficiency enhancement and 20% energy consumption reduction;
3. High productivity double-shaft mixer

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

High Quality Mobile Asphalt Mixing Plant for Road Construction Engineering

Asphalt mixing plant 1Asphalt mixing plant 2Asphalt mixing plant 3Asphalt mixing plant 4
