HMI Flat Precision screen printer with vacuum table

HMI  Flat Precision screen printer with vacuum table
Model:PS-4060PVS
Brand:KC
Origin:Made In China
Category:Industrial Supplies / Plate Making & Printing Machine
Label:screen printer , silk printer , screen machine
Price: US $7260 / pic
Min. Order:1 pic

Product Description

To further improve the accuracy of the flat screen printing machine, in addition to using a linear guide mechanism for guiding control, the main action can also be controlled by a servo motor. The main action of the flat screen printing machine is the up and down motion of the screen and the left and right motion of the scraper. The movement control of the motor can be digitally set through the programmable controller, and the screen plate can be adjusted up and down, and the scraper can be fine-tuned. For products with many product specifications and frequent parameter adjustments, the servo screen printing machine is easy to operate. Sex is also praised by the operator.

PS-4060PVS Flat precision screen printing machine with vacuum table //Structure

Working table

Vacuum working table, Size: 500*700mm

Actions

Up-down of screen plate

To be printed

  • Plain objects

Squeegee stroke

Adjust the Limited switch

Squeegee and screen plate control

 High precision linear guideway

PS-4060PVS  Flat screen printing machine with vacuum table //Usage and characters

Guide

  • Fit printing soft and thin products such as paper, plastics film etc;
  • With vacuum working table ensure adsorbing object when printing;
  • Working table keep stillness but screen frame moving from up and down so that objects easy to put on and take off;
  • Also widely used in Glass plate, Machine panel screen printing;
    With UV curing machine, Can finish many UV special printing process including UV Spot Varnish, UV frosting , UV glitter Powder ;
  • Suitable for printing sheet-fed adhesiving sticker;
  • Suitable for printing water transfer label and heat transfer label through diffrent process;
  • Max Printing area: 400*600mm;
  • High Precision liner guideway installed to controll the movement of Rubber squeegee and screen frame. widely used to print circuit aboard , Film switch panel etc industrial field.

Application

  • Widely used in Glass printing field;
  • With UV curing machine, Can finish many UV special printing process for UV package industry.
  • Suitable for printing Mobile windows ;
  • Suitable for printing water transfer label and heat transfer label through diffrent process;
  • The machine panel, plastic parts, Paper, furniture industry, glass industry, circuit board industry, film, wooden case, Precision Electron circuit

PS-4060PVS Flat screen printing Machine with vacuum table//Parameters

Technical parameters

  • Max printing thickness: 150 mm;
  • Air consumption: 80Litre/Min;
  • Dimension of working table: 500×700mm;
  • Max printing areas: 400×600mm;
  • Max printing speed: 1000Pcs/H;
  • Max frame dimension: 600×950mm;
  • Compress air: 5-7 bar;
  • Stroke of cylinder up and down:160mm;
  • Stroke of Squeegee: 600mm;
  • Table Precision: 0.05mm;
  • Rang adjustment of table: 10mm.

Works supply

  • 110V-220V Power supply;
  • 5-7Barcompress air;

Package parameters

  • Package dimension: 1270×990×1820mm
  • Gross weight: 260kg;
  • CBM: 2.2883

H.S.CODE

8443192190

Certificate

CE

PS-4060PVS Flat screen printing Machine with vacuum table //Advantage

Function

  • Touch screen program control operation technology, famous brand electronic and electrical components assembly;
  • Screen lift is controlled by precision servo motor with linear guide rail;
    Front and rear and rotation fine-tuning functions of worktable and screen frame;
  • High-precision stainless steel fine grinding platform, evenly distributed 1.5mm suction holes, X-Y precision fine-tuning device design;
  • The ink scraping and ink return devices are controlled by servo motors and linear guides;
  • With vacuum suction function, powerful automatic vortex vacuum pump, tight adsorption, to ensure accurate multi-color registration.
Application: To further improve the accuracy of the flat screen printing machine, in addition to using a linear guide mechanism for guiding control, the main action can also be controlled by a servo motor. The main action of the flat screen printing machine is the up and down motion of the screen and the left and right motion of the scraper. The movement control of the motor can be digitally set through the programmable controller, and the screen plate can be adjusted up and down, and the scraper can be fine-tuned. For products with many product specifications and frequent parameter adjustments, the servo screen printing machine is easy to operate. Sex is also praised by the operator.
