Shrimp De Heading Machine  Description

Model: ZL-D100

Pouring machine

Technical parameters:

Machine dimensions: L2100xW1560xH1300mm

Pouring method: Hydraulic pump driven

Power: 2.2KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 300KG

Brief instroduction: Pouring machine mainly lifts shrimp raw material or others by hydraulic pump to the lifting machine!

Application: shrimp, fish raw material and others!



Lifting machine

Technical parameters:

Machine dimensions: L3500xW1300xH1600mm

Lift method: by high strength nylon belt

Power: 1.5KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 500KG

Brief instroduction: Lifting machine mainly lifts shrimp raw material by conveyor to the de-heading machine!

Application: shrimp, fish raw material and others!



ZOLIM De-heading machine

Technical parameters:

Machine dimensions: L3200xW630xH1600mm

De-heading method: by drum

Power: 0.8KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 1500KG

Brief instroduction: De-heading machine mainly put shrimp which head-on to the drum, then by  run up and beat to achieve head and body separate!

Application: shrimp head on!



Lifting machine

Technical parameters:

Machine dimensions: L2000xW1100xH1300mm

Lift method: by high strength nylon belt

Power: 0.4KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 400KG

Brief instroduction: Lifting machine mainly lifts shrimp raw material by conveyor to another machine!

Application: shrimp, fish raw material and others!



Lifting machine

Technical parameters:

Machine dimensions: L3000xW1550xH1700mm

Lift method: by high strength nylon belt

Power: 1.5KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 450KG

Brief instroduction: Lifting machine mainly lifts shrimp raw material by conveyor to the vibrator machine!

Application: shrimp, fish raw material and others!



Vibrator machine

Technical parameters:

Machine dimensions: L1500xW1150xH1000mm

Power: 0.8KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 200KG

Brief instroduction: Vibrator machine mainly let shrimp raw material be placed more evenly through vibration!

Application: shrimp, fish raw material and others!



Sizing machine

Technical parameters:

Machine dimensions: L4840xW2540xH1695mm

Pouring method: by differences in optical properties

Power: 4.5KW

Power supply type: 380v/3p/50Hz

Capacity: 1000-1500KG/H

Weight: 2200KG

Precision:>=95%

Air compressor: 30kw

Bleed pressure: 0.3-0.6Mpa, Air consumption: 2.5-4.4m3/min, Air collector: 1.5m3

Brief instroduction: Sizing machine mainly separate shrimp head from body by differences in optical properties!

Application: shrimp, and others!
