GSK RB03A1 Handling Robot Brand Juze Motion Radius (mm) 1410 Repeat Positioning Accuracy (mm) ± 0.05 Payload (kg) 8 Drive Mode AC Servo Drive Degree of Freedom 4 Place of Origin Guangzhou Quantity 99 Available National Model RMD08 Guang Several brands of robot system motor drive warranty for three years 1) The movement speed is fast and the movement speed is fast.Stamping beat can be as high as 14 times / min.2) Large range of motion Compared with the traditional swing arm robot with a motion range of less than 500mm, the maximum working radius of RMD08 can reach 1410mm, which can be easily applied to punching occasions where the center distance of the punch press is 2.5m.3) Stable performance and long service life. The RV reducer is used for the first, second and third axes. Compared with the harmonic reducer used by the swing arm manipulator, the service life and impact resistance can be doubled, and the stability and feeding accuracy are higher.4) Good general performance ① There is no requirement for the tonnage of the equipment and the height of the punching machine, and multiple machines can be connected.The customer's production line is automatically upgraded, and there is no need to replace the machine tool equipment, saving investment by 50% to 60%.②Compared with the swing arm type manipulator, the vertical range of movement is larger, and the stamping and unloading, palletizing, and handling processes are performed.The project's swing arm manipulator palletizing stamping robot has a low range of up and down motion, generally within 500mm.Large range of motion, flexible action Stamping, loading and unloading, unstacking, palletizing, and handling can all be protected against harmonics, screw rods, slide rails and other structures are difficult to protect, easy to enter dust and water, reduce performance stability, and shorten lifespan 3 One set of RV reducer and one set of harmonic reducer The structure is easy to seal, good protection, no need for frequent oiling and lubrication Low maintenance cost Stamping cycle ≈10 (times/min) ≈14 (times/min) Rigid and easy to shake Good rigidity and no vibration Motion track end point to point straight line, arc, curve

Dongguan Hypertron Intelligent Technology Co., Ltd
specializes in the production of special manipulators for

injection molding machines and other automation equipment,

spot welding robots, handling robots, general-purpose robots,

and spraying robots, which can improve automatic productivity,

production stability, production efficiency and Quality, and

appropriately reduce production personnel, so that the

injection molding production plant has a more competitive

advantage in the market.The company provides customers with

the best overall automation solutions and services from

product planning and design, manufacturing, assembly, sales,

and service, and is widely used in electronics,

communications, automobiles, home appliances and other

fields.Provide high-quality, high-efficiency, and reasonably

priced automation products for the plastic industry.

General items: research and development of intelligent robots;

manufacturing of industrial robots; installation and

maintenance of industrial robots; sales of industrial robots;

sales of intelligent basic manufacturing equipment;

manufacturing of intelligent basic manufacturing equipment;

manufacturing of industrial automatic control system devices;

sales of industrial automatic control system devices;

Manufacturing; sales of intelligent instruments and meters;

manufacturing of power electronic components; sales of power

electronic components; general mechanical equipment

installation services; network and information security

software development; Import and export of goods; import and

export of technology.
