T-64947GD031HU-T-AAN
Screen size : 3.1inches


Active area : 68.4(W) x 41.04(H) mm


Dot pixels : 800(W) x 3[R.G.B] x 480(H)

Pixel pitch : 0.0285(W) x 3[R.G.B] x 0.0855 (H) mm


Pixel arrangement : RGB stripe

Color depth : 16.7M colors


LCD type : TFT / Normally black-mode / Transmissive


Surface treatment : Glare  / Surface hardness ）: Min.3H

Front polarization axis angle : 0° （Horizontal direction

Data transfer : LVDS(JEIDA Format) data transfer 8bit or 6bit + GPU

Backlight  : None

Drawings  : Dimensional outline  T-57636AB_base Rev. B

Outline dimensions : 74.7(W) x 51.4(H) x 1.228(D) mm


Weight  : 12.4 g typ. 14.9 g max.

About the backlight to be used : The brightness of the backlight is less than 2 million cd/m2

 Please evaluate long-term reliability carefully in advance.

RoHS regulation : This product satisfies material requirement of
Europe E nstructions Europe E nstructions and RoHS regulation.
