Basic Info.

Model NO.

GS-32

Feed Cylinder Structure

Multi-Room Feeding

Filling Principle

Filling

Structure

Linear

Packaging

Bottle

Packaging Material

Bottle

Product Name

Candy Tablet Capsule Electronic Counting and

Working Range

Adjustable From 2-9999 Per Bottle

Air Supply

0.6MPa,45-60L/Min

Material

Stainless Steel

Transport Package

Plywood Case

Specification

2200*1400*1680mm

Trademark

NOAH

Origin

China, Jiangsu

Product Description

GS-32 Pill Candy Tablet Capsule Electronic Counting and Filling Machine



Applications:

The GS-32 Pill Candy Tablet Capsule Electronic Counting and Filling Machine combines 32-channel counting channels. Compact design with dual-track conveyor can enhance the capacity of output. This equipment is mainly used for bottle packing of tablets (including abnormal tablets), capsules, gels (including transparent gels and opaque gels) pills and similar solid granules. Highly accurate counting.

Technical Parameters:

Applicable	0-5# capsules, soft gels, ф5.5-15 normal tablets, special shape tablets, coating tablets, ф3-12 pills
Capacity	40~70 BPM
	18000~31500 bottles/shift
Working range	Adjustable from 2-9999 per bottle
Power supply	220V/50Hz 2.2kw
Air supply	0.6Mpa,45-60l/min
Size	2200*1400*1680mm
Weight	650kg
Remarks	1. Capacity is subject to the type and size of the bottle and tablet, as well as the quantity filled per bottle; 2. *BPM=Bottles per minute
