Model: | SM019-D525 |
---|---|
Brand: | Shineman |
Origin: | Made In China |
Category: | Computers & AV Digital / Computers / Embedded Computer & SCM |
Label: | D525 , 1U industrial pc , network firewall |
Price: |
US $110
/ pc
|
Min. Order: | 5 pc |
●Soldered down Intel Pineview platform Atom D525 Processor
●Integrated Intel GM3150 Graphics
●Single Channels DDR3,Max.4G/800MHz
●1*mPCIE,Supports mSATA SSD
●6*Gbe LAN,10/100/1000M Base-Tx Gbe Compatible
●12V Power supply
Specification
Processor |
Intel Pineview Platform Atom Processor D525 |
Chipset |
Intel NM10 |
Graphics |
Intel GM3150 Graphics |
Display |
1*VGA |
Memory |
1*DDR3 SO-DIMM,Max.4GB DDR3/800MT/s |
Ethernet |
6*Intel 82574L, Supports WOL、PXE Boot |
Storage |
2*SATA2.0 |
1*mPCIE,Supports mSATA SSD |
|
Rear Panel I/O |
1*PWR_BTN |
1*RST_BTN |
|
1*RJ45 COM |
|
2*USB2.0 |
|
1*PWR_LED+HDD_LED |
|
6*LAN |
|
Internal I/O |
1*CPU_FAN |
1*SYS_FAN |
|
2*SATA2.0 |
|
2*SATA_PWR |
|
1*ATX_4P |
|
1*LAN_LED |
|
1*VGA_H |
|
1*mPCIE |
|
1*AUTO_ON |
|
1*CLR_CMOS |
|
1*GPIO |
|
1*F_Panel |
|
BIOS |
8M Flash ROM |
Power Supply |
DC 12V |
OS |
windows10/11/Linux |
Heat Sink |
Smart Fan |
OTR |
-10℃~60℃ |
STR |
-20℃~70℃ |
Humidity |
5%-95% Relative Humidity,Non-condensing
|
Dimension |
Motherboard: 180*200mm |
Chassis: 440*282*44mm |
