Model: OKU-60HK
Brand: OREKU Hui Elbow Punch
Precision: JIS Special Grade
Speed: 750 times/min
Tonnage: 60 tons
Travel: 30mm

IC lead frame precision high-speed punching machine automated production line
Pressure capacity: 600KN
Travel: 20/25/32/40 mm
Strokes: 100-750/100-750/100-650/100-550 spm
Closed mold height: 220-300 mm
Sliding block adjustment amount: 80 mm
Slide size: 1130 x 500 mm
Worktable size: 1100 x 600 mm
Workbench thickness: 140 mm
Workbench opening size: 800 (top) x 700 (bottom) x 100 mm
Bed opening size: 840 x 120 mm
Main motor: 22 × 4P kw
Upper mold weight: MAX450 kg
Total weight: 14000 kg
External dimensions: 2840 x 3170 x 1540 mm
60 ton gantry high-speed punch brand
Xinhao Hui Elbow Punch
60 ton gantry high-speed punch model
IC lead frame precision high-speed punching machine automated production line

IC lead frame precision high-speed punching machine automated production line
The price of the 60 ton gantry high-speed punching machine is determined based on the tonnage and travel configuration chosen by the customer, with a range of prices ranging from 30 tons to 500 tons.
Applicable range of 60 ton gantry high-speed punching machine
Various precision terminal stamping, various mesh holes, lead frames, Madading rotors, precision shrapnel, etc
