8F OS2 Singlemode MPO MTP Trunk Cable

Model:	-
Brand:	-
Origin:	Made In China
Category:	Electronics & Electricity / Optical Fiber, Cable & Wire / Communication Cable
Label:	MTP Trunks , MPO Trunks , Trunk Cable
Price:	-
Min. Order:	100 pc

Inquire Now

Product Description

8F OS2 Singlemode MPO MTP Trunk Cable

MTP/MPO Trunk Cable is compact, high-density fiber optic connector assemblies designed for high-density applications. Our MTP/MPO Trunks are suitable for applications up to 100G for connecting equipment or interconnecting modules/panels within a data center. The MTP/MPO connectors come in Standard and Elite versions to accommodate various power budget requirements of our customers.

Feature:

USCONEC; SENKO; NISSIN; SUNCALL; Chinese brand

Different MT inserts available (Base-8, Base-12,Base-16, Base-24)

Color-Coded Connector Boots for Easy Identification

Corning ClearCurve® YOFC Fiber with 7.5mm Min. Bend Radius

Available OFNR、OFNP、CPR(B1ca/B2ca/Cca/Dca/Eca)

Available in single sheath (2.0mm to 3.0mm, typically overall length ≤15m) and double sheath (4.5mm to 5.5mm)

RoHS2 Certification

Technical Parameters:

Connector A	MTP® Female (Pinless)	Connector B	MPO Female (Pinless)
Polish Type	UPC to UPC	Glass Fiber	Corning Clear Curve®
Fiber Mode	OS2 SMF 9/125μm	Wavelength	850/1300nm
Fiber Count	8 Fibers	Polarity	Type B
Cable Outside Diameter(OD)	3.0mm-17.3mm	Cable Jacket	Plenum(OFNP)
Min.Bend Radius(Optical Fiber)	7.5mm	Min.Bend Radius (Fiber Cable)	20/10D(Dynamic/Static)
Connector Durablity	500 times	Tensile Strength(Long/ShortTerm)	80/240N
Insertion Loss	0.35dB Max(0.15dB Typ.)	Return Loss	≥20dB
Attenuation at 850nm	≤2.3dB/km	Attenuation at 1300nm	≤0.6dB/km
Operating Temperature	-10 to 70℃(14 to 158F)	Storage Temperature	-40 to 85℃
Glass Fiber	Corning, YOFC	Operating Temperature	-10 to +70°C
