1. Introduction



The 1.8 Degree 42mm 2 Phase Linear Stepper Motor is an advanced motor designed specifically for applications that require precise linear motion. It combines the well - known principles of stepper motor technology with a linear design to provide reliable and accurate movement in a straight line.

2. Key Specifications

(1) Step Angle



With a step angle of 1.8 degrees, this linear stepper motor offers high - precision positioning. In applications such as linear positioning systems in semiconductor manufacturing or precision assembly lines, the small step angle allows for extremely fine and accurate movement control. This ensures that components can be positioned with minimal errors, contributing to the high quality of the end - product.

(2) Motor Size



The 42mm dimension gives it a relatively compact size, making it suitable for integration into various equipment where space is a consideration. In automated inspection systems or small - scale production setups, the 42mm linear stepper motor can be easily incorporated without taking up excessive space, while still providing the necessary power and precision for linear motion.

(3) Phase Configuration



The 2 - phase design provides a stable and efficient way to control the linear motion. It offers a good balance between generating the required force for linear movement and maintaining accurate positioning. Compared to other phase configurations, the 2 - phase system simplifies the control process, making it more accessible for designers and engineers to integrate the motor into their linear motion applications.

3. Performance Characteristics

(1) Precise Linear Motion



This motor is engineered to provide highly accurate linear movement. It can move along a straight line with precision, making it ideal for applications that demand exact positioning, such as in 3D printing of linear structures or in the movement of precision slides in optical equipment. The linear motion is repeatable, ensuring consistent performance over multiple operations.

(2) High Force Output



Despite its relatively compact size, the motor can generate sufficient force for linear motion. In applications like linear actuators in industrial automation or in the movement of heavy - duty linear stages, the motor's force - generating capability allows it to handle the load effectively and move it smoothly along the linear path.

(3) Smooth Operation



The motor operates smoothly, with minimal vibration and noise during linear motion. In environments such as laboratories or clean rooms, where quiet and stable operation is essential, the smooth operation of the motor ensures that it does not interfere with sensitive equipment or processes. This also reduces wear and tear on the motor and associated mechanical components, increasing its lifespan.

(4) Good Speed Control



It offers excellent speed control capabilities within a certain range. Users can adjust the speed of the linear motion according to the specific requirements of the application. In applications such as automated packaging lines with variable speed needs or in high - speed 3D printing of linear parts, the motor's speed control feature allows for optimal performance.

4. Applications

(1) Industrial Automation



In industrial automation, the 1.8 Degree 42mm 2 Phase Linear Stepper Motor is widely used. It powers linear actuators for tasks such as pushing, pulling, or positioning in manufacturing processes. It can also be used in conveyor systems with linear sections, ensuring precise movement of products along the conveyor line.

(2) 3D Printing



In the 3D printing industry, this motor is used to control the linear movement of the print head in some specialized 3D printers that focus on linear or geometrically simple designs. The precise linear motion enables the creation of accurate and high - quality 3D models with straight edges and precise dimensions.

(3) Precision Equipment



In precision equipment such as linear positioning stages in microscopy or in the movement of precision tooling in machining centers, the motor provides the necessary accurate linear motion. This allows for precise alignment and operation of the equipment, contributing to accurate measurements and high - quality machining.

(4) Laboratory Automation



In laboratory automation systems, the motor is used for tasks such as sample handling, where precise linear movement of the sample holder is required. It can also be used in automated liquid handling systems for accurate positioning of pipettes and other dispensing tools.

5. Conclusion



The 1.8 Degree 42mm 2 Phase Linear Stepper Motor is a highly specialized and reliable motor for linear motion applications. Its combination of precision, force output, and smooth operation makes it an excellent choice for a wide range of industries, from industrial automation to laboratory and precision equipment.
