1. Automatic feeding with adjustable brackets

2. Speed is adjustable for different products

3. 54mm hole diameter for SKD11/DC53 thread rolling dies

4. Max. Rolling pressure is about 150KN

5. It is easy to operate and maintain the machine

6. CE, ISO9001-2008



Specification
Working diameter	4-60mm
Thread pitch	0.8-5mm
Thread length	In feed or Thru feed
Spindle speed	28/35/45/56rpm
Outside diameter of rolling die	135-178mm
Inside diameter of rolling die	54mm
Thickness of rolling die	120mm
Min.center distance between die spindles	120mm
Max.center distance between die spindles	240mm
Main motor	5.5KW
Hydraulic motor	2.2KW
Max. Rolling pressure	15T
Supply voltage	380V 3P 50Hz
Weight(reference)	2500(KG)
Dimension(L*W*H)	1560*1550*1260 mm
Package Dimension(L*W*H)	1600*1540*1550 mm



Q1. Are you factory or trading company ?

A1. We are factory of manufacturing thread rolling machine and dies by ourselves.

      Welcome to visit our factory, if possible.



Q2. What is the delivery time ?

A2. Usually 15-25 working days for machine, and 10-15 working days for dies.



Q3. What is the warranty time for machine?

A3. Usually 12 months from B/L date.



Q4. What is the payment term?

A4. T/T, Western Union, Money Gram, Alipay, PayPal.

      50% as deposit, and 50% before shipping.



Q5. Is it possible to design and produce automatic loading & unloading devices?

A5. Yes, Engineer can design special auto feeding device according to your products.

      But please provide the drawing of your products before that.



Q6. How will you solve problems that we face during using your machine?

A6. A. Please provide necessary videos and pictures that can show the problems, our engineers will check        and give corresponding solutions.

      B. Will arrange engineers to solve problems at the scene, if possible.
