CBB21 Metallized Polypropylene Film Capacitor(MPP Ser.)

CBB21  Metallized Polypropylene Film Capacitor(MPP Ser.)
Model:CBB21(MPP)
Brand:SY
Origin:Made In China
Category:Consumer Electronics & Lighting / Lighting / LED Lighting
Label:capacitor , AC capacitor , mkp capacitor
Price: US $0.04 / pc
Min. Order:10000 pc
Inquire Now
点击这里给我发消息

Product Description

Reference standard

GB10191-1998     IEC60384-16

Climatic categort

40/85/21

Rated voltage

50V/63V/100V 160/250V 400V 630V

Capacitance range

0.0047—10.0µF

Capacitance tolerance

±5%(J)   ±10%(K)   ±20%(M)

Voltage proof

≥1.6UR  (5S)

Dissipation factor

≤0.008  (20℃ 1.0KHz)

Insulation resistance

(20℃ 1min)

≥30000MΩ

C≤0.33µF

≥10000MΩ/µF

C> 0.33µF

Advantages:Are non-inductively wound with metallized polypropylene film as the dielectric / electrode with copper-clad steel leads and epoxy resin coating.

※Very low loss at high frequency, high dv/dt

※High insulation resistance, long life due to self-healing effect

※Widely used in high frequency, DC, AC and pulse circuits ability due and suitable for high current
CBB21  Metallized Polypropylene Film Capacitor(MPP Ser.) 1CBB21  Metallized Polypropylene Film Capacitor(MPP Ser.) 2CBB21  Metallized Polypropylene Film Capacitor(MPP Ser.) 3
