Support RS232 and RS485 interface CCTV Security Tester STest-894

Model:	vc-STest-894
Brand:	vichan
Origin:	Made In China
Category:	Security & Protection / Surveillance Equipment
Label:	cctv tester , STest-894 , camera tester
Price:	US $216 / pc
Min. Order:	1 pc

Inquire Now

Product Description

Name：

CCTV Security Tester STest-894

Color：

Performance Features：

1.CCTV system installation and maintenance 2.Dome camera and All in one camera testing 3.The CCTV transmitting channel testing 4.PTZ controller

Product parameters ：

The CCTV testerPRO STest-894 for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, testing video level, controlling PTZ, scanning PTZ address, generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down.

Application:
1.CCTV system installation and maintenance
2.Dome camera and All in one camera testing
3.The CCTV transmitting channel testing
4.PTZ controller
　

FEATURES

3.5"TFT-LCD , 960（H）×240（V）resolution

Digital Multimeter, performs AD/DC Voltage, AC/DC Current, Resistor, Conductivity, Capacitor and Diode test.

DC12V power output

Audio input

Adjustable brightness, contrast, color of LCD

Video Level testing, video signals measured in IRE or mV

Automatically identify and adapt the video mode of NTSC and PAL

Colorbar Video signal generator, transmit/receive colorful images

Support more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc.

PPTZ address scanning, search up the ID of PTZ camera.

Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.

Support RS232 and RS485 interface, the rate 150-19200bps

Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection

PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset.

Lithium Ion Polymer Batteries(3.7V DC3000mAh), more reliable, and work 15 hours

Easy for use that the train is almost unnecessary

SPECIFICATIONS
　

MODEL	STest-894 CCTV Security Tester
Video Test
Signal mode	NTSC/PAL (Auto Adjust)
Display	3.5 inch TFT-LCD ,960 x 240 resolution
LCD adjust	Adjustable brightness, contrast, color of LCD
Video IN/OUT	1 channel BNC Input & 1 channel Output
Video Output Mode	1.0 Vp-p
Video Level test
Level test	Video signals measured in IRE or mV
Power Output
Power output	DC12V, 1A
Audio Test
Audio input	1 channel Audio input
PTZ controller
Communication	RS232, RS422 simplex and RS485
PTZ Protocol	Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.customized
Baud Rate	150,300,600,1200,2400,4800,9600,19200bps
Video Signal Generation
Color bar generation	Output 1 channel color bar video signal for testing monitor
UTP CABLE TEST
UTP cable test	Test UTP cable connection state and display in the screen. Read the number of the test box.
PTZ data Capture and display
PTZ Data Test	Capture and Analyze the PTZ data sent from controlling device
PTZ address scanning
PTZ address scan	Search up the ID of PTZ camera
Digital Multimeter
Reading range	-6600~+6600
AC/DC Voltage	0-600V Auto/Manual ranging, 0.1mV resolution
AC/DC Current	6.6mA, 66mA, 660mA, 10A Manual ranging
Resistor	660, 6.6K, 66K, 660K, 6.6M, 66MΩ auto/manual range
Continuity	Built-in buzzer will sound, if resistance is lower than 50Ω
Diode	2.0V Range, 1mV resolution
Capacitor	6600pF~66,000μF auto/manual range
POWER
Power Adapter	DC5V, 2A
Battery	1 pcs Lithium Ion Polymer Batteries, 3.7V DC3000mAh
Rechargeable	4.5 hours recharging time, work for 12 hours
Low Consumption	Sleeping mode, display battery power state
Other Parameters
Work Temperature	-10℃---+50℃
Work Humidity	30%-90%
Dimension/Weight	112mmx189mmx47mm / 500g
