1. introduction:

STABLE serial products are hand swipe operated magnetic card reading machine with USB interface, adopting high integrated magnetic card decoding chip. They have small electricity consumption and strong interference resistance. They comply with ISO-7811 ISO-7812 magnetic card decoding standard completely. It can read card bi-directional, free to choose data with or without enter keyboard has intelligent lights to alert if card data is read correctly. Exquisite magnetic installation structure makes card reading more stable and reliable, which is our patented technology. Reasonable product design makes products small and compact.





ii.              Features:

       1&2&3 Track read

      Manual-swipe type reader

      Bi-directional reading capability

      USB HID interface (HID keyboard & HID custom)

      ISO 7811, CA_DMV/AAMVA standards conformance and custom format

      Operation responded by two LED and buzzer

     Head rated 800,000 passes,electronics rated 125,000 hours

      Power supplied by PC USB

      DLL/OCX developing kit for Windows (HID custom mode)

      Card feeding Speed : 12 to 120 cm/sec



iii.              Applications:

      POS System

      Security Control

      CAT(card authorization terminal )





iv.              Environment Requirements:

      Ambient Temperature

- Storage : -20 C to +80 C

- Operating : 0 C to +60 C

      Ambient Relative Humidity

- Storage : 0 to 95%

- Operating : 10 to 90%



v.              Physical Characteristics:

      Color:black

      Weight:80g

      USB cable length:1.5m

      Current:Less than 45mA

      Operating Locus:Indoor only

      Power Supply:DC 5V +/- 5% ( Supplied from the host computer )

      Dimensions:90mm ( D ) X 27mm ( W ) X 28mm ( H )



Reading/Writing magnetic stripe card complied with ISO formats

Read/Write High & Low Coercive (300~4000Oe) really 4000OE

High/Low Coercivity encoding circuitry selectable on screen

Program software for Windows 98/Me/XP

Sequential write function, up to 12 digits (1 up)

Manual Swipe to read and/or write card with USB output

+24VDC, 2.5A Max external power adapter attached

Dimensions of 210(L) x 60(W) x 62(H) mm
