WES-100D Electro-hydraulic (digital display) Universal Testing Machine

1. Introduction

The machine adopts hydraulic loading, digital display, easy and convenient to operate. It is mainly used to measure the properties of tension, compression, bending for metal materials and also can do the compression and bending test to other materials like plastics, cement and concrete, etc.

There is a connector on the controller to connect to the computer for upgrading to servo testing machine.

2. Main technical parameters

1) Max force: 100KN

2) Measuring range: 0-100KN

3) Accuracy of indicated value: 1%

4) Max distance between tensile jaws: 550mm

5) Max distance between upper and lower platens: 450mm

6) Diameter of upper and lower platens: 160mm

7) Clamping diameter of round specimen: 6-13mm, 13-26mm

8) Clamping range of flat specimen: 0-15mm

9) Max clamping width of flat specimen: 70mm

9) Clamping mode: hydraulic
