Reading Speed: 100 pcs tags/s(tag ID number),200 pcs tags will be read at same time

Reading Distance: Greater than 100 meters

Working Frequency: 2.4-2.48G

Frequency Power: ≤30 dBm , can be adjusted by software

Reading Sensitivity: -90dBm

Microwave Communication: CRC16

Antenna: build-in non-direction antenna

Working Voltage: 6~12V DC(MAX 30mA)

Interface: RS232/485/Wiegand/TCPIP/CANBUS

Baud Rate:9600

Working Temperature: -40°C ~ +80°C

Storage Temperature: -60°C ~ +80°C

Electronic Magnetic In EMI:  10V/m 0.1~1000MHz AM

Reliability:  MTBF ≥ 70000 hours

Feature
Character                                                                      Advantages
100 paces tags/s                                                        reading speed High speed identification
200 paces tags be read at same time                    Identify many people at same time
Real-time operation system                                      Reliability and stability
Frequency power can be adjusted by software     Reading distance 20 meter
2.45GHz Microwave working frequency                      High speed, long distance. Low power consumption
