Flyin Optronics’ 1x1 Mechanical Fiber Optic Switch (1x1 Optical Switch) connects optical channels by redirecting an incoming optical signal into a selected output fiber. This is achieved using a patent pending opto-mechanical proprietary configuration and activated via an electrical control signal.
All Flyin Optronics’ 1x1 Mechanical Fiber Optic Switch (1x1 Optical Switch) support all wavelength at 1260nm~1650nm, it offers ultra-high reliability, low insertion loss, fast switching speed as well as bi-directional performance. The optical switches are widely used for Optical Network, Protection, Transmitter and Receiver Protection,Network Test System and Instrumentations.
Features
l Low Insertion Loss
l Wide Wavelength Range
l Low Crosstalk
l High Stability, High Reliability
l Epoxy-free on Optical Path
l Latching and Non-latching
Applications
l Channel Blocking
l Configurable Add/Drop
l System Monitoring
l Instrumentation
Performance Specifications
|
Parameter |
|
FY-1×1T |
|
|
Wavelength Range |
nm |
850 |
1260~1650 |
|
Operating Wavelength |
nm |
850 |
1310/1490/1550/1625/1650 |
|
Insertion Loss |
dB |
Typ:0.5 Max:0.8 |
Typ:0.4 Max:0.6 |
|
Return Loss |
dB |
SM≥50 MM≥30 |
|
|
Crosstalk |
dB |
SM≥70 MM≥65 |
|
|
PDL |
dB |
≤0.05 |
|
|
WDL |
dB |
≤0.25 |
|
|
TDL |
dB |
≤0.25 |
|
|
Repeatability |
dB |
≤±0.02 |
|
|
Power Supply |
V |
3.0 or 5.0 |
|
|
Lifetime |
Times |
≥107 |
|
|
Switch Time |
ms |
≤8 |
|
|
Transmission Power |
mW |
≤500 |
|
|
Operating Temperature |
℃ |
-20~+70 |
|
|
Storage Temperature |
℃ |
-40~+85 |
|
|
Dimension |
mm |
(L)27×(W)12.6×(H)8.0 (±0.2) |
|
Specification may change without notice.
Above specification are for device without connector.
Pins
|
Type |
Pin |
Electric Drive |
Status Sensor |
||||||
|
1×1 |
|
Pin 1 |
Pin 5 |
Pin 6 |
Pin 10 |
Pin 2-3 |
Pin 3-4 |
Pin 7-8 |
Pin 8-9 |
|
Latching |
P1-P2 |
V+ |
GND |
-- |
-- |
Open |
Close |
Close |
Open |
|
Light close |
-- |
-- |
GND |
V+ |
Close |
Open |
Open |
Close |
|
|
Non-latching |
P1-P2 |
V+ |
-- |
-- |
GND |
Open |
Close |
Close |
Open |
|
Light close |
-- |
-- |
-- |
-- |
Close |
Open |
Open |
Close |
|
Optical Route
|
Specifications |
Voltage |
Current |
Resistance |
|
5V latching |
4.5~5.5 |
36~44mA |
125Ω |
|
5V non-latching |
4.5~5.5 |
26~32mA |
175Ω |
|
3V latching |
2.7~3.3 |
54~66mA |
50Ω |
|
3V non-latching |
2.7~3.3 |
39~47mA |
70Ω |
Ordering Information
|
X |
XX |
X |
X |
X |
XX |
X |
XX |
|
Mode |
Wavelength |
Voltage Type |
Control Model |
Fiber Type |
Fiber Diameter |
Fiber Length |
Connector |
|
S=SM M=MM |
85=850nm 13=1310nm 14=1490nm 15=1550nm 62=1625nm 65=1650nm 13/15=1310/1550nm X=Others |
3=3V 5=5V |
L=Latching N=Non- Latching |
5=50/125 6=62.5/125 9=9/125 X=Others |
25=250um 90=900um 20=2.0mm 30=3.0mm X=Others |
1=1m 2=1.5m X=Others |
0=None 1=FC/PC 2=FC/APC 3=SC/PC 4=SC/APC 5=ST/PC 6=ST/APC 7=LC/PC 8=LC/APC X=Others |
