JRF-PM150 Thermal Pad has excellent thermal conductivity and electrical insulation performance. Not only can satisfy the majority of electronic product thermal insulation requirements, but also widely used in the thermal requirements that are not too high in electronic products. With the heat conduction performance, stable and the product also has the viscosity, easy to use.

JRF-PM150 Thermal Pad using the heat conduction, soft silicone heat-conducting material stable insulation performance characteristics and soft and elastic, good contact is arranged between the heating device and the heat radiating member, which achieve heat transfer and insulation effect.

Applications:
1.LED lighting, lighting equipment
2.Household appliances LCD display
3.Between semiconductor and radiating fin
4.Communication product, smart phone, tablet .
5.Desktop, notebook and other portable computer
6.Large power supply etc.

Performance and characteristics:
1.High thermal conductivity, heat transfer coefficient 1.5W/m-k
2.Stable performance, low thermal resistance, effectively improve the heat  transfer speed
3.Low hardness, its viscosity, easy to use and high degree of bonding
4.By UL and V-O certification standards

Specification:
◆Standard size : 200mm*400mm 310mm*310mm,according to customer needs cutting type.


◆Basic thickness 0.25mm~15mm, special thickness size can be customized

◆Itself slightly viscous, if need to strengthen the adhesive can be according to customer’s requirement


◆Product color is mass production color , special color you need, we can adjust according to the actual situation .
