Mini Plc Controller DC 24v Integrated Development Environment OpenPCS

Model:PLC-IO-8000
Brand:GCAN
Origin:Made In China
Category:Electronics & Electricity / Electric Control System
Label:industrial parts , expandable , modular
Price: US $129.9 / piece
Min. Order:1 piece
Inquire Now

Member Information

Detail

Product Description

GCAN-IO-8000/8100 —— with CANopen & Modbus communication protocol



Performance CANopen adapter (GCAN-IO-8000) Modbus adapter (GCAN-IO-8100)
Node number 1~127 1~247
Baud rate 10Kbps~1000Kbps 600bps~115200bps
Power input 24V DC (18~36V)
Insert I/O module number 32 pieces (at most 32*8 IO point)
Dimension 100mm*69mm*48mm
Working temperature, humdidness -40℃~+85℃, 0~90%RH, without condensation
IP grade IP20
Module feature
  • Standard CANopen slave station
  • Support 4 TPDO, 4 RPDO
  • Support 1 SDO, 1 emergency object, 1 node error control object
  • Start to perdefine connection, suppor parameters store
  • PDO mode supports synchronization, looping, event-driven, polling
  •  Configuration mode is automatic configuration
  • CAN interface: one open 4 terminal
  • Input current, 70mA+ ( total GC-bus current), maximum 2.5A
  • Starting current: about 2.5 times continuous current
  • Power contacts: maximum 24V DC/maximum 10A
  • Electrical isolation: 1500 Vrms
  • Support standard Modbus protocol, a standard Modus slave station
  • Support Modbus function code:01, 02, 03, 04, 05, 06, 15, 16
  • Support CRC validation
  • Support Modbus TCP, Modbus RTU communication (corresponding to two kinds of style)
  • RS485 interface adopts standard two-wires system
  • Serial interface baud rate supports 600bps~115200bps, configured by serial interface
  • The maximum number of bus terminals module is 64
  • Configuration mode is automatic configuration, expandedfreely
  • Ethernet interface supports static or dynamic IP acquisition
  • Ethernet interface supports heartbeat and timeout disconnection
  • Ethernetwork interface is fixed, target IP and target interface can be set
  • Automatic restoration of connection resources after the Ethernet interface is disconnected,and reliable establishment of TCP connections
  • Ethernet interface is compatible with the SOCKET working mode (TCP Server, TCP Client,UDP, etc.). The upper computer communication software complies with the standard SOCKET rules.
  • Input current, 70mA+ (total GC-bus current), maximum 4500mA
  • Starting current: about 2.5 times continuous current
  • Power contacts: maximum 24V DC/maximum 10A
  • Electrical isolation: 1000 Vrms (power contact/bus coupled powervoltage)
  • Standard DIN rail,designed for industrial design



GC-1008~8012 —— with digital & analog and special IO modules

IO Module Selection Table
I/O Type Characteristic Signal Channel
Digital input GC-1008 Digital input (PNP) 24V DC 8-channel
GC-1018 Digital input (NPN) 24V DC 8-channel
GC-1502 Counter(200kHz max) 2-channel
Digital output GC-2008 Digital output (PNP) 24V DC 8-channel
GC-2018 Digital output (NPN) 24V DC 8-channel
GC-2204 Relay output 4-channel
GC-2302 PWM (20Hz~200kHz) 2-channel
Analog input GC-3604 Voltage input, 16 bits -5~+5V 4-channel
GC-3624 Voltage input, 16 bits -10V~+10V 4-channel
GC-3644 Current input, 16 bits 0-20mA 4-channel
GC-3654 Current input, 16 bits 4-20mA 4-channel
GC-3664 Voltage input, 16 bits 0~+5V 4-channel
GC-3674 Voltage input, 16 bits 0~+10V 4-channel
GC-3804 2-wire PT100, 16 bits Thermal resistance 4-channel
GC-3814 2-wire PT1000, 16 bits Thermal resistance 4-channel
GC-3822 3-wire PT100, 16 bits Thermal resistance 2-channel
GC-3832 3-wire PT1000, 16 bits Thermal resistance 2-channel
GC-3844 K type thermocouple Thermocouple 4-channel
GC-3854 S type thermocouple Thermocouple 4-channel
GC-3864 T type thermocouple Thermocouple 4-channel
GC-3874 J type thermocouple Thermocouple 4-channel
Analog output GC-4602 Voltage output, 16 bits -5V~+5V 2-channel
GC-4622 Voltage output, 16 bits -10V~+10V 2-channel
GC-4642 Current output, 16 bits 0-20mA 2-channel
GC-4652 Current output, 16 bits 4-20mA 2-channel
GC-4662 Voltage output, 16 bits 0~5V 2-channel
GC-4672 Voltage output, 16 bits 0~10V 2-channel
GC-4674 Voltage output, 12 bits 0~10V 4-channel
Special module GC-6101 RS232/RS485 extension
GC-6201 GPRS extension
GC-6501 WiFi extension
GC-8012 Power extension




Product Image

Mini Plc Controller DC 24v Integrated Development Environment OpenPCS 1
Img 1
Mini Plc Controller DC 24v Integrated Development Environment OpenPCS 2
Img 2
Mini Plc Controller DC 24v Integrated Development Environment OpenPCS 3
Img 3
Mini Plc Controller DC 24v Integrated Development Environment OpenPCS 4
Img 4
Mini Plc Controller DC 24v Integrated Development Environment OpenPCS 5
Img 5
