| Model: | FS2(KP22)-T+ZP |
|---|---|
| Brand: | KP |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Terminal |
| Label: | cable connector , connectors , water proof plug |
| Price: |
US $2.8
/ PAIR
|
| Min. Order: | 10 PAIR |
| Last Online:13 Dec, 2024 |
FS2 series circular connectors made of plastic shell,It can be useed in the water-proof place.We use the reliable cage clamp connection instead of the traditional wire spring.These connectors have the features of lower contact resistance,anti-libration,shock proof,water proof and strong seal etc.They are widely used for the electrical connection between electrical equipment.It has protection IP68(Test : Under water 2 m ,48 hours).Meet CE,RoHs.UL certification:E308558.Patent No.:201220427726.X.
Product Ordering
FS 2 -- 3 T - 6
1 2 3 4 5
1. Name of series： fs
2.Design No. : 2
3.Number of contacts： 2,3,4,5,6
4.T: Plug with sockets, ZM: Panel receptacle with solder pins,Use M12 metal hex screw,ZM1: Panel receptacle with solder pins,Use M12 Plastic hex screw, ZP:cable receptacle with solder male pins.(Z1:receptacle with crimp pins.)
5. Cable gauge: 5,6,7(The cable OD),only plug and cable receptacle meet cable.
| Specifications: | Product Ordering FS2 — 3 T - 6 1 2 3 4 5 1. Name of series： FS 2.Design No. : 2 3.Number of contacts： 2,3,4,5,6 4.T: Plug with sockets, Z: receptacle with pins,ZP:cable receptacle with pins 5. Wire gauge: 5,6,7 kp22-3t-5/kp22-3zp-5; kp22-3t-6/kp22-3zp-6; kp22-3t-7/kp22-3zp-7; kp22-5t-6/kp22-5zp-6; kp22-5t-7/kp22-5zp-7; kp22-5t-5/kp22-5zp-5; |
|---|---|
| Advantages: | small size,light weight; Current:10A The length of FS2-3T/3ZP is 72mm. IP68,Under water 1m. Meet CE,RoHs.UL file:E308558.Patent No.:201220427726.X. |
| Pricing: | us$2.8 |
| Payment Details: | t/t |
| Min Order: | 10 |
| Ship Date: | 5 day |
| Standard Met: | IP68 |
