RP1226 14分支器Y形电缆低压注塑RP1226 14分支连接器电缆 - CT007-193919 - COMTECH (中国广东省生产商) - 汽车部件和附件

RP1226 14分支器Y形电缆低压注塑RP1226 14分

J1939 female plug	equivalent of Deutsch HD16-6-12S
Type of J1939 female plug	Type 1
Color of J1939 female plug	GREY
J1939 male plug	equivalent of Deutsch HD16-6-12P
Type of J1939 male plug	Type 1
Color of J1939 male plug	GREY
Wire	18AWG, pure copper
Material of J1939 plug	PA66 + glass fiber
Material of D-SUB 15PIN plug	PBT
Pin assignment or pin out	customized
Cable length	customized
Pins or terminals	copper, nickel-plated or gold-plated
Contact Resistance	3 ohm max.
Insulation Resistance	5M ohm min.
Working Temperature	−25℃ ~ +85℃
Testing	100% open, short and mis-wire testing
Testing Voltage	DC300V 5M ohm/10ms
Warranty	1 year
