No

Item

Performance

1

使用温度范围

Operating Temperature Range

-40 to + 1050C

-25 to +1050C

2

定格电压范围

Rated Working Voltage Range

6.3－63V.DC

100－450V.DC

3

静电容量范围

Capacitance Tolerance

0.1－15000µF

0.47－1000µF

4

静电容量容许差

Capacitance Tolerance

±20%(at+250C,120HZ)

5

泄漏电流

Leakage Current

 I≤0.01V or 3（µA）max

I≤0.03CV or 20（µA）max

                                          L: Leakage Current （µA）

Whichever is greater after 3 minutes.  C: Rated Capacitance （µF）

                                          V: Working Voltage  （V）

6

损失角

Dissipation Factor(tanδ)

（120Hz\+25℃）

For capacitance value ＞1000µF, add 0.02 per another 1000µF

7

温度特性（at 120 Hz）

Characteristics at low temperature （stability at 120HZ）

For capacitance value >1000µF,Add 0.5 per another 1000µF for -25℃/+25℃.

                    Add 1.0r another 1000µF for -40℃/+20℃

8

高温负荷特性

High Temperature Loading

After 2000hrs. application of DC rated working voltage at +105℃.

The capacitor shall meet the following limits:

Post test requirements at + 25℃

9

高温无负荷特性

Shelf Life

After storage for 1000hrs. at+105℃ with no voltage applied.

Post test requirements at+25℃

Same limits for high temperature lading.
