12V的铅酸电池充电器

型号：	FYxxxyyyy
品牌：	Fuyuang
原产地：	中国
类别：	电子、电力 / 电池、蓄电池、充电器
标签︰	充电器 , 电池充电器 , 铅酸充电器
单价：	-
最少订量：	300 件

发送查询

产品描述

14.6V Series For 12V Lead-Acid Battery Charger

■ Features

·Universal AC input / Full range

·Plastic or metal case optional

·Cooling by free air convection

·MTBF:30000 hours

·Provide 3 years warranty

·Install fuses on both ends of the Input and Output for double safety

·Protections:Short circuit / Over load / Over voltage / Over temperature

·Meet CEC,DoE Level VI,Energy star,ErP stage 2,CoC Tier 2,NRCan & GEMS

·Certification:UL,ETL,CUL,GS,CE,BS,SAA,KC,PSE,CB,FCC,EMC,RoHS,REACH

SPECIFICATION

OUTPUT

MODEL NO.

FY1501000

FY1502000

FY1503000

FY1504000

FY1505000

FY1506000

FY1507000

FY1509900

OUTPUT VOLTAGE

9-14.6V

OUTPUT CURRENT

10A

OUTPUT POWER

14.6W

29.2W

43.8W

58.4W

73W

87.6W

102.2W

146W

PFC (MIN.)

0.6

0.9

RIPPLE & NOISE (max.)

150mVp-p

INPUT

INPUT VOLTAGE RANGE

100 ~ 240VAC

FREQUENCY RANGE

50 / 60Hz

INPUT POWER

NO LOAD: 0.5W MAX AT INPUT 100-240VAC 50/60Hz . LOADING : 150W MAX , AT RATED OUTPUT .

TEMPERATURE RISING

CASE 65 ℃ MAX .℃ FOR RATED OUTPUT

EFFICIENCY (MIN)

88%

DIELECTRIC WITHSTAND TEST

5mA 3000VAC FOR 60 SECOND BETWEEN INPUT AND OUTPUT INPUT AND CASE, AT AN ALTERNATIVE POTENIALS 5% HIGHER MAY BE APPLIED FOR 1 SECOND

PROTECTION

OVER LOAD

THE PRODCT INCLUDES CURRENT FUSE TYPE 250V 3A LOCATED WITHIN INPUT CIRCUIT

SHORT CIRCUIT:

CAPABLE OF WITHSTANDING CONTINUOUS SHORT CIRCUIT AND RECOVER AUTOMATICALLY

ENVIRONMENT

WORKING TEMP RANGE

THE OPERATIN TEMPERATURE OF THE PRODUCT SHALL BY FROM -29 ℃ TO + 45 ℃

STORAGE TEMPERATURE

THE STORAGE TEMPERATURE OF THE PRODUCT SHALL BY FROM -40 ℃ TO + 75 ℃

RESISTANCE TO HEAT

WHEN TESTED WITHIN 10 MINUTES AFTER PRODUCT HAS BEEN PLACED IN A TEST CHAMBER MAINTAINED AT105 ±3℃ FOR 16 HOURS , THE PRODUCT SHALL COMPLYVAC WITH THE REQUIREMENTS OF 4.7 , DIELECTRIC WITHSTAND TEST , SHALL HAVE INSULATION RESISTANCS NOT LESS THAN STATED BELOW AS MEASURED AT 500VDC 10 MEGOHMS MINIMUM BETWEEN THE INPUT AND THE OUTPUT, INPUT AND CASE TOGETHER , 10 MEGOHMS MINIMUM

RESISTANCE TO MOISTURE

THE PRODUCT SHALL BY PLACED IN A TEST CHAMBER MAINTAINED AT 40 ± 2 ℃ AT 90% ~ 95% RELATIVE HUMIDITY FOR 6 HOURS . THEN , WHEN TESTING 10 MINUTES SAFTER THE PRODUCT IS TAKEN OUT FROM THE TEST CHAMBER AND WIPED DRY , THE PRODUCT SHALL COMPLY WITH THE REQUIREMENTS OF 4.7 DIELECTRIC WITHSTAND TEST , AND SHALL HAVE INSULATION RESISTANCE NOT LESS THAN STATED BELOW AS MEASURED AT 500VDC 10 MEGOHMS MINIMUM BETWEEN THE PRIMARY AND THE SECONDARY TOGETHER;10 MEGOHMS MINIMUM BETWEEN A SECONDRY THER SECONDRY AND TOGETHER.

SAFETY & EMC

SAFETY STANDARDS

UL60950 EN60335

EMI

CISPR22 CLASS

INSULATION

OTHERS

MTBF

THEVDESIGN AND CONSTRUCTION OF THIS PRODUCT EXHIBIT A MINIMUM MEAN TIME BETWEEN FAILURE OF 30000 HOURS FULL RATED LOAD OPERATION AT 25 ℃

CONNECTOR

PLUG

5521, 5525, RCA, XLR, XT60, M16, C14.
