TDS-100H手持式超聲波流量計：

TDS-100H portable ultrasonic flowmeter:


適用於各種尺寸管道流量計量，流速測量範圍為0.01～±32m/s,測量介質為水、海水、污水、酒精等單一穩定的液體，管道材質為鋼、不鏽鋼、鑄鐵、PVC、玻璃鋼等均可以測量。

   Applicable to all kinds of sizes of pipe flow measurement, Flow velocity measurement range of 0.01 ~ + 32m/s, Measurement of medium is water, water, sewage, alcohol and other single stable liquid, Pipe material for steel, stainless steel, cast iron, PVC, steel and glass can be measured.


測量精度：優于1%；

Measurement precision: Better than 1%;


重複性：優于0.2%；

Repetition: Better than 0.2%;


工作電源：內置鎳氫充電電池可持續工作10小時以上；

The working power supply: The built-in rechargeable Ni MH battery sustainable work more than 10 hours;


傳感器安裝方式：外夾式安裝；

Sensor installation: Outer clip mounted;


顯   示：4行漢子同屏顯示瞬時流量、流速、累積流量、信號狀態等；

Display: 4 men with screen display instantaneous flow, velocity, flow accumulation, signal status etc.;


信號輸出：隔離RS232，可用於聯網檢測或導出記錄數據；

The signal output: The isolation of RS232, Can be used for network detection or export data;


可選輸出：OCT輸出正、負、淨累積脈衝信號和頻率信號（1-9999HZ）可選；

Optional output: OCT output positive, negative, net cumulative pulse signals and frequency signals (1-9999HZ) optional;


可選配的傳感器：外夾式，可即插即拔式接口；

The sensor can be selected: Clamp, which can plug and play interface;
