membrane switch dedicated tunnel oven with uv curing system

Model:	TAM-IR 885
Brand:	Tamprinter
Origin:	Made In China
Category:	Industrial Supplies / Plate Making & Printing Machine
Label:	IR OVEN , Tunnel oven , IR Tunnel oven
Price:	US $8000 / SET
Min. Order:	1 SET

Inquire Now

Product Description

1. Name of the tunnel oven: membrane switch dedicated tunnel oven
2. Model of the tunnel oven: TAM-IR 885
3. Overall dimension: Total length 8000mm* total height 1270 mm* total width 850 mm;
4. Temperature range: Atmospheric temperature～+250℃ (adjustable);
5. Meter measurement accuracy: ≤±0.1℃;
6. Temperature uniformity: ≤±5℃(no-load);
7. Power supply: Three-phase and five-wire system, 380 V, 50 HZ;

Product introduction

Unique performance

Customer optional configuration

Liner mirror surface is made of stainless steel, with better clean class;

Inside is made of high-quality insulation material, with good insulation effect;

Fast temperature rise, stable and precise temperature;

Double over-heating protection, electric controlled, safe and reliable;

Conveyor belt is frequency controlled, conveying speed is stable and adjustable;

Conveyor belt anti-draft device is set, conveyor belt tightness is adjustable;

Intelligent temperature controller, PID auto calculation, LED display;

Imported SSR/SCR output control unit, high temperature control precision;

Domestic first class heat insulation technology, excellent sealing effect;

Low temperature of machine shell, small influence on indoor ambient temperature;

Energy efficient, power saving, safe and environmental

Can be filled with nitrogen for protection and realizing non-oxidation drying environment.

Color, temperature control system, conveyor system can be selected according to the customer requirement;

Color selection legend

Customer can designate color according to the color chart.

※Match different charging trays/trolleys according to the dried product, the material includes baking varnish, electroplate color zinc, stainless steel, etc., dimension, specification can realize non-standard customization, welcome to telephone to consult.

optional item

Optional control system
Button switch control	Touch screen human-computer interface

Optional conveyor belt
Stainless steel net belt	Teflon net/cloth belt	Attachment chain conveyor belt
Chain board conveyor belt	Bi-pitch chain through rod conveyor belt	PCB conveyor chain
Glass industry conveyor system	PVC belt	High temperature resistant canvas conveyor belt
Trolley conveying	Drum type conveying	Non-standard customized conveyor system

Temperature control optional equipment

Temperature controller
Taiwan CAHO intelligent temperature controller		FUJI intelligent temperature controller
Japanese imported OMRON temperature controller		Honeywell temperature controller
Temperature recorder
multi-channel color screen paperless recorder		multi-channel paper recorder
Imported PARTLOW circle diagram temperature recorder		Imported YOKOGAWA 48 channel temperature recorder
Record group
Portable temperature recorder group 12 points		IR computer temperature recorder group 12~48 points
Touch screen +PLC
Weinview 7		Proface
Mitsubishi		Siemens
IPC Ethernet remote monitoring

Timer 30 points, imported LED digital timer, 0-9999 S/M/H can be set, MM/DD/YY programmable timer
Electric power output, electric power auto adjuster according to SSR, SCR, SSPR, etc.

Air circulation legend


Single side air supply type	Double side air supply type	Double side air supply anti-explosion	Thermal radiation ascending type

All-round radiation type	Thermal radiation irradiation type	Hot air radiation type	Hot air radiation type
