Fully automatic A/C system flushing and cleaning machine

Model:	HO-X800
Brand:	HONOW
Origin:	Made In China
Category:	Industrial Supplies / Machinery / Heat Exchange & Air Conditioners
Label:	refrigerant recovery , recovery machine , a/c service station
Price:	-
Min. Order:	1 pc

Inquire Now

Product Description

Features

* Recovery/Recycling (drain used oil)

* Vacuum

* Refill new oil

* Recharge

* Recycle-cleaning,makes flushing of lines, evaporators, and condensers fast and easy. Forward Cleaning & Reverse cleaning.

* It's an advanced A/C hose service equipment , with unique on-car AC hose recycle and cleaning function. No need any chemicals,only use refrigerant to change waste oil in the system and clean the whole system.

* Sight Glass — To observe flow rates and cleaning process.

* Simple pipeline connection.Operation starts once the hose of the machine is connected to the interface of the air conditioner yet to be tested.

* Data print.

* Database search

* High-precision electronic scale weighs the refrigerant filling and reclaiming.

* Its purification & filtration system efficiently ensures recovery of used refrigerant.

* It employs high-duty vacuum pump.

* It adopts unique automatic protection design to prevent liquid attack and ultra-high pressure explosion.

* Main components are originally imported to guarantee excellent performance.

Performance Parameters

Type of refrigerant	R134a , can be customized
Service procedure	Fully automatic or manual
Recovery rate	97% , stop at 0 bar automatically
Recovery speed	350 g/min
Charge speed	1500g/min
Vacuum speed	120 liter /min
Vacuum pump	Double stage 2L pump
Cycle cleaning time	20-40mins
Refrigerant tank	13.6kg
Compressor	Danfoss brand , SC15G

Advantages

a. It employs two stage high performance vacuum pump ( VALUE) . Throgh a dual stage vacuum pump ( 100-140 lit/ min ) , large 4mm orifice solenoid valveand 3/8" vacuum hose . Silencing blocks on the vacuum pump keeps the running noise down .

b. Main components are originally imported to guarantee excellent performance .

c. Database search and data printed report .

d. It's an advanced A/C system on car flushing and cleaning machine , no need any chemicals , only use refrigerant to change waste oil in the system and clean the whole system .
