Automatic PE PVC stretch film slitting and rewinding machine
| Model: | JC-R05S |
|---|---|
| Brand: | JCD |
| Origin: | Made In China |
| Category: | Industrial Supplies / Packaging Related Machine |
| Label: | rewinding machine , slitting machine , slitter rewinder |
| Price: |
-
|
| Min. Order: | 1 pc |
Product Description
Shenzhen JCD machinery Co., ltd is a profeesional manufacturer of high quality equpment for slitting & cutting & rewinding & laminating the matherial with glue or without glue. Our main product including : adhesive tape cutting machine, rewinding machine, BOPP tape slitting rewinding machine, PET film slitting machine, OCA film slitting machine and rewinding machine.
Our machine are wildely used in the film, paper, adhesive tape and other industiries.Our factory have been in the filed more than 15 years. The machiners have been exported to many countries and regions, have gaind good reputationos from the clients home and abroad.
1) Product Name: PE & PVC stretch film machine for rewinding
2) Function: Rewind the stretch film jumbo roll to log roll
3) Main Technical Parameters
| Model | 0.9M or as customized |
| Mother roll and paper core loading mode | Manual |
| Max diameter for the parent roll | 500mm |
| Inner diameter of the parent roll | 3'' |
| Width of sub-roll | 50-500mm |
| Inner diamter of the sub-roll paper core | 3'',2'',1.5'' or as customized |
| Paper core I.D | 20mm or as customized |
| Max. rewinding diameter | 200mm |
| Speed | 0-200M/Mi |
4 ) SPECIFICATION:
1. Two shafts rewinding, to save the working time.
2. Main function of the panal: Two-step length counter, showing the speed of the rewinding shaft to control the movement of the shaft.
3. Two-step length setting ensure the precision of the log roll rewinding length.c
| Payment Terms: | LC、TT |
|---|---|
