The 100-year star technology UBLOX module BG-828 uses UBLOX-UB X-M8030-KT chip size: 28mm * 27mm * 6.5 mm BG-828 GPS module has the advantages of high performance and low power consumption. Inherited the excellent performance of the U-blox M8 GNSS engine and used industry-certified NEO packaging. The BU-1216 module can receive up to 3 GNSS systems(GPS/Galileo and Beidou or GLONASS) at the same time. It can identify multiple constellations at the same time and still provide excellent positioning accuracy in urban canyons or weak signal environments. In order to improve positioning performance better and faster, it also supports message integrity protection, geographic fencing and fraud detection, and has configurable interface settings that can easily adapt to customer applications.
The product can be used to develop a variety of GPS terminal products such as: automotive navigation, automotive security systems, vehicle monitoring, flight control flight models, CarLog and other satellite positioning applications.
Module performance parameters state:
Sensitivity tracking-167 dBm
Cold Start-148 dBm
Hot start-157 dBm
TTFF
(initial positioning time)
Cold start 26S(open area)
Warm start 2S.
Hot start 1S
Type 72 Channel U-blox M8 Engine
Frequency GPS L1 C/A, GLONASS L1 FDMA QZSS L1 C/A
Supports WAAS, EGNOS, MSAS,
Positioning accuracy 2.0 M
Speed accuracy 0.1 m/s
Time pulse(configurable) 100m/s(default)
Maximum update rate 1HZ -- 10HZ
PPS 10ns
Running Limit Height Max & lt; 18000m
Speed Max & lt; 515 m/s
Acceleration & lt; 4G
Data Format NMEA 0183 Protocol
Power supply 2.7 V to 3.6 V
Power consumption 50mW
VBAT 7uA
Size encapsulation 28mm * 27mm * 7mm
Oscillator TCXO
Antenna passive antenna passive antenna
Temperature Operating Temperature -40 °C to +85 °C
Storage temperature-40 °C to +85 °C
Standard meets RoHs.
