Model: | RNCF 7088H |
---|---|
Brand: | RONA |
Origin: | Made In China |
Category: | Security & Protection / Access Control System |
Label: | Flap Barrier Gate , Turnstiles Gate , Flap barrier Gate |
Price: |
-
|
Min. Order: | 1 pc |
Tenical Parameters
Description | Parameters |
Item / Model | RNCF 7088H |
Running life | 5 millions |
Drive voltage | DC24V 20W |
Pass Speed | 30-40 persons/minute |
Open direction | Unidirectional and bi-directional (optional) |
Opening time | 0.6S (adjustable) |
Color | Silver |
Thickness of Housing | 2.0mm |
Input port | relay dry contact signal; +12V level signal and pulse width >100ms, DC12V pulse signal |
Product Description
Flap turnstiles is a hight-tech product which mainly provides intelligent management to passageway.
This product is finely processed with complete function and high level ,suitable for high-level neighborhoods intelligent building, hotel, subway, port and club,ect.
Standard Functions & Features of Servo Flap Turnstiles Gate
1) When out of power, the turnstile open automatically without storage battery. |
2) DC Brushless Motor, Maintenance Free. |
3) With direction indication, guiding passenger to entry and exit. |
4) Self automatic locking to prevent forcedly passing without the card |
5) Light and sound alarm indication function, preventing illegal entry or irregular passing |
6) Rapid identification technique, available to identify accurately and efficiently the magnetic card, bar code card, ID card and IC card. |
7) Automatic counting and displaying number of passenger, facilitating observation and with a displaying total amount as high as 90,000 |
Extend Functions
The flap turnstile system is provided with a standard electric interface and can easily integrates the common 3rd party equipment with read/write facilities.
1. | access control system |
2. | bar-code scanner |
3. | Token /ID/IC card reader |
4. | time & attendance system |
5. | coin collector |
6. | card collector |
7. | consumption system |
8. | ESD system and fare collection system |
9. | biometric systems (fingerprint & face recognition) |
