SAFT Term Analysis

When the specimen is loaded with a certain standard mass, the upper limit temperature that it can bear when the adhesive region is sheared to failure is the shear failure temperature SAFT.



Test principle

By controlling the heating rate of the oven, the time for the adhesive failure of the adhesive tape specimen is measured, and then the shear failure temperature is calculated.



Specifications

1. Thermostat resolution accuracy: 0.1 ° C;



2. Sample cutter: width 24MM;



3. Test area: 24 mmX24 mm;



4. Test plate: 72 mm long and 50 mm wide;



5. Manual or electric rolling wheel (purchased separately);



6. The accuracy of temperature meter is 0.5 min;



7. The initial temperature is 40 ° C;



8. Test load: 1KG or 0.5KG, 9 in total;



9. Temperature range: normal temperature+5 ° C~300 ° C;



10. Temperature uniformity: ± 1 ° C;



11. Temperature control system: touch screen type, can set time, temperature, speed, and can set different temperature range program group test mode;



12. Number of test groups: 9 groups in total, with each group timing separately and staggered front and back;



13: Internal 304 stainless steel, external advanced powder spraying treatment;



14. Power supply: 220V 2KW
