Digital radiography NDT x-ray system is equipped with different high-energy X-ray flaw detection machines, which can meet a variety of testing samples and different testing environments. According to different test samples, can choose different models of X-ray machine. Compared with the traditional potentiostatic X-ray machine and radiation detection means, the super-large imaging detector can meet the needs of a variety of samples detection, sample detection situation is displayed on the computer in real time, and the experimental results can be saved and printed.

Product Advantages of Digital Radiography NDT X-ray System

● The small x-ray generator with wind cooling by anode grounding

● The light weight for easy to take, and easily operate it

● Working rate of digital x-ray system 1:1

● Reasonable design with nice performance

● Delayed exposure to make sure the operator's safety

Specifications

2135 Model detector of Digital Radiography NDT X-ray System

Detector mode:  A-si                     Scintillator:  GOS

Image size:  350MM×210MM       Pixel matrix:  2560×1536

Pixel pitch: 139μm                         A/D conversion: 16bit

Space solution:  3.6 LP/mm           Captured image time:  1s(wired)/2.5s(wireless)

Energy of X-rays:  40~450kV         Weight:  2.9kg

Working environment: 5~35℃， 10~75%RH

Specification of portable DR system:
