| Feature |
| SHFIVE3520 is the new generation multi-function processing machine which is associated to be designed and manufactured between SHOOT and research institute of famous college. With pattern operation and advanced control system and synchronous CNC control system, the machine can be easily operated easily without knowing complicated CNC knowledge. |
| This machine can be used to realize some advanced functions like : cutting line, chamfering, drilling, profiling, 3D profiling, and edge profiling, which can be used to small processing factory and countertop shops. |
| 1. Compact size without needing the ground base. |
| 2. With advanced CNC control system and all pattern operation, the machine can be operated without professional operators. |
| 3. With powerful functions, the machine can work almost all the jobs of a small factory. |
| 4. With less electricity and more efficiency, the cost is decreased much. |
| 5. High quality accessories and electric parts are used to secure long service life and low cost. |
| Model |
SHFIVE3520 |
| Programming method |
Image input |
| Control method |
CNC |
| Power |
4KW,7.5KW,11KW |
| Working voltage |
380V-3phase/50HZ |
| R.P.M |
1000-6000r/min |
| Blade size |
350mm |
| X-axis working stroke |
3500mm |
| Y-axis working stroke |
2000mm |
| Z-axis working stroke |
400mm |
| A-axis working stroke |
360°free rotation |
| B-axis working stroke |
0-90 degree chamfer automatically |
| X axis walking speed |
1-15000mm/min |
| Y axis walking speed |
1-12000mm/min |
| Z axis walking speed |
1-2000mm/min |
| A cutting speed |
0-7r/min |
| Cutting thickness |
100mm |
| Processing precision |
0.2mm |
| Working table size |
3500*2000mm |
| Tilting working table |
80° |
| Overall size |
5800*3120*3320mm |
| Weight |
4300KG |
| |
|
| |
|
| Operation model : |
| 1.Code Mode: all pattern operation, no G-code |
| 2.Control Mode: PC |
| 3.DXF pattern is supported to be imported |
| 4.The updating of main program needs only one key |
| 5.Multi language operating interface |
| 6.The metric and British system can be shifted easily |
| 7.The data can be backup and copied to new machine easily |
| 8.With function of pause |
| 9.Table can be tilted to 85 degree for easy loading |
| 10.Pneumatic device can support easy moving of big slab |
