| 180W CNC Laser Router Machine |
| Feature |
| 1. With DSP digital control technology, international general laser power supply, integrated frame structure design, the working process is more stable. |
| 2. The latest intelligent software directly supports the output of AutoCAD, CoreIDRAW and other software. The output mode of high-speed USB2.0 interface can realize complete offline operation. Visual large screen liquid crystal display, visual large screen liquid crystal display, friendly human-computer interface, make the operation easier. The control system is equipped with large memory, which can store multiple files at the same time and output selectively. The software is compatible with all vectors. Image format. |
| 3. Design new models with unique structure according to market demand to avoid material waste. Super light beam, narrow cutting seam, smooth edge, large cutting force, greatly improving work efficiency. |
| 4. Anti fatigue CO2 laser tube, equipped with imported reflector, focusing lens, prolong the service life. |
| 5. Perfect function of power off and carving |
| 6. Imported linear guide rail and belt drive, equipped with deceleration structure, cutting more smooth. Stable. High power stepping motor, stronger driving force. |
| 7. Optional and diversified configuration: red light positioning, negative pressure adsorption, automatic lifting platform, rotating shaft and other equipment. |
| Applicable materials: surface processing or cutting of organic materials such as double color board, glass, crystal, wood board, high density board, stone, rubber, leather, plexiglass, cloth, acrylic, etc |
| Application Industry: handicraft and gift box, crystal production, portrait, picture carving, two-color plate carving, advertising industry, building model, seal and printing plate making, leather decoration and cutting, Yuanling stone tablet portrait carving, automobile instrument, leather manufacturing, mold model, packaging industry, etc |
| Model |
SH1325L200 |
| Laser type |
Closed CO2 laser tube |
| Driving mode |
Stepping drive |
| Control software |
Ruida / lechuang |
| Cutting width |
1300*2500mm |
| Operation mode |
Carving / scanning / cutting / slope carving |
| Standard air pump |
450W |
| Standard fan |
330W |
| Positioning method |
Red light location |
| Speed of movement |
≤1000mm/s |
| Working voltage |
220v/60hz |
| Resolving power |
1000dpi |
| Positioning accuracy |
0.0254mm |
| Support format |
BMP、JPEG、GIF、PLT、AI、TGA、DXP、TIFF、PCX etc. |
| Minimum formed text |
English 1mm Chinese 2mm |
| Laser power |
180W |
| Auxiliary device |
Suction fan and exhaust device |
| Whole machine power |
300W ≤ 1000W depending on the laser and accessories selected |
| Packing |
Air cushion film |
| Weight of whole machine |
435kg |
