Stone Cutting Machine, Waterjet Cutting Machine(DIPS9-3040)
380Mpa UHP system: The pressure is high, the cutting ability strong, cutting surface quality is good, cutting speed, especially for thickness in above 30mm hard material cutting (such as steel, aluminum, copper and other metal and stone, ceramic, etc. ), as well as to cut the surface quality and the cutting speed is taught in high demand occasion. Sizes: DIPS9-3040, DIPS9 - with, DIPS7 - with, DIPS9D - 5540 etc.
Waterjet cutting system---UHP System Dardi (Model: DIPS9-3040)
Intensifier Qty.: 1
Max. Pressure: 300MPa/40000psi
| UHP System |
| Model |
DIPS6-2230 |
DIPS9-3040 |
DIPS9-6040 |
DIPS9-7540 |
DIPS7-3740 |
| Drive system |
| Drive system |
Motor |
| Pressure system |
| Pressure system |
Intensifier |
| Intensifier Qty. |
1 |
1 |
2 |
3 |
1 |
| Specification Date |
| Max.pressure |
300MPa/40000psi |
380MPa/55000psi |
400MPa/60000psi |
| Max.Flow rate |
3.1L/min |
3.7L/min |
7.4L/min |
11L/min |
3.7L/min |
| Power |
22kw/30HP |
30kw/40HP |
60kw/80HP |
75kw/100HP |
37kw/50HP |
| Pressurization rate |
24:1 |
20:1 |
20:1 |
20:1 |
20:1 |
| Oil Pressure |
0-150 bar |
0-200 bar |
| Oil type |
46#(15-40ºC)
Hydraulic oil 46#(Environment 15-40ºC) |
| Power Supply |
220/380/415VAC 3 Phase |
