DIN Male Connector For 3/8 Superflex Cable(solder type)in good VSWR
| Model: | 7/16-H-J3/8S-1 |
|---|---|
| Brand: | Customized |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Telecommunication & Broadcasting / Other Communication Equipment |
| Label: | DIN Male Connector , 3/8 Superflex Cable , solder type connecto |
| Price: |
US $1.8
/ pc
|
| Min. Order: | 1 pc |
Product Description
7-16(DIN) coaxial connectors-high-qualtiy coaxial connectors with low attenuation and inter-modulation.Transmission of medium to high power with redio transmitters and low PIM transmission of received signals such as in mobile phone base stations are typical applications due to their high mechanical stability and best possible weather resistance.
|
Interface |
|||
|
According to |
IEC60169-4 |
||
|
Electrical |
|||
|
1 |
Characteristic Impedance |
50ohm |
|
|
2 |
Frequency Range |
DC-6GHz |
|
|
3 |
VSWR |
1.15 |
|
|
4 |
Dielectric withstanding voltage |
≥2500RMS,50Hz,at sea level |
|
|
5 |
Dielectric Resistance |
≥5000MΩ |
|
|
6 |
Contact Resistance |
Outer Contact≤1.0mΩ ;Center Contact≤0.0mΩ |
|
|
Mechanical |
|||
|
1 |
Durability |
Mating cycles ≥500 |
|
|
Material and plating |
|||
|
1 |
Description |
Material |
Plating |
|
2 |
Body |
Brass |
Ni |
|
3 |
Insulator |
PTFE |
– |
|
4 |
Center conductor |
Phosphor bronze |
Ag |
|
5 |
Other |
Brass |
Ni |
|
Environmental |
|||
|
1 |
Temperature Range |
-40℃~+85℃ |
|
1.CNC machines ,advanced test equipment
2.All products are suit for ROHS.
3.ISO14001 certificate,ISO9001 certificate
Packaging & Shipping
Company Information
Certifications
FAQ
|
Q:what's your company MOQ? |
|
A: It depends on whether use customers' brand or not, than we can negotiate. |
|
Q: What's your delivery time? |
|
A: It depends on our stock in first, products can send out once receive your deposit. If use customer brands, it will depends the quantity, we will ofen take a bout 7days to prepare materials and mass production. |
|
Q: Can your company accept customize? |
| A: Welcome OEM & ODM. |
|
Q: How do you solve after sale service? |
|
A: This please ask us for technical support if you have workers know how to repair. If do not have engineers, please send back the items, we can repair the items for you. |
|
Q: Can you send a sample for us to develop? |
| A: Yes, we can. Sample can send out once you ask for it, but will ask a sample fee. Sample fee will return back in future order. |
