Performance Characteristics
1.Impact specimen gap hydraulic broaching machine is the only instrument gap for processing the qualified sample except the optical curve grinding machine. Because of once processing theory,the identity of processing the gap is very nice.
2.This broaching machine adopts W18Cr4V manufacturing,high hardness, wear resistance, and every tool can process the sample as many as 20 000.
3.It can meet GB/T 2106-80 “metal Charpy (V-type notch) impact test method” and GB/T 229-2007
 “metal Charpy (U-type notch) impact test method”, as well as the requirements of domestic and international standards of ASTM E23, ISO148 and ISO083.
4. First two V-or U-notched only need 8 seconds operation, extremely simple and reliable.

Gap type Standard
V (2mm) was randomly attached GB/T 229-2007,ASTM E23
U (2mm) was randomly attached GB/T 229-2007

Technical Parameters
Model    CSL-Y
Gap in the shape of the specimen    V-or U-(2mm)
Processing the sample size    10*10(7.5 or 5)*55mm
Cutting mode    electric
cutting speed    2.5m/min
Broach  stroke    350mm
Broach Materials    W18Cr4V
Power    380V 50HZ 0.4Kw
Dimensions (mm)    650*400*1200
Weight    180Kg
